● Overview
9610L Series Linear actuators fully electronic single-phase power supply is 220V AC power as a drive to accept DC4 ~ 20mmA or DC1 ~ 5V control signals from the controller to operate a fully electronic actuator. Electronic control unit is designed box shape and resin casting ; drive motor with AC reversible motor ; feedback detect the amount of driving high-performance conductive plastic potentiometer, high reliability, economy type products with 1/250 the ability to differentiate .
The actuator is adopted when implementing agency for the regulation , the regulation itself almost demands with various actions and opening signal conversion function function (4 ~ 20mA) and manual functions.
● The main technical parameters
Power supply : AC200V
Control signal : DC4 ~ 20mA, DC1 ~ 5V ( external wiring far avoided DC1 ~ 5V)
Output signal : DC4 ~ 20mA, DC1 ~ 5V
Mode of operation: switch replacement with positive and negative actions
Resolution: < 0.4%
Adjustment range : zero to 20% ± 25% to 100% of stroke
Permissible ambient temperature : Normal No space heaters -10 - +60 ℃ have a space heater -35 - +60 ℃ flameproof -10 - +60 ℃
Allow vibration : 1.5g or less (g is the gravitational acceleration )
Relative Humidity: 95% less common type flameproof 45% -85 %
Explosion-proof mark : Exd Ⅱ BT4
